Product Details

Pedinghaus Ocean Avenger 40 1000/1C (2017)


Model: Ocean Avenger 40 1000/1C

Year: 2017

Reference #: 100219

Not Available

Max Beam Size: 40" Beams x 40'
Max Beam Weight: 730 lbs.
Min Drill diameter: 1/4"
Max Drill diameter: 2"
Max Material Thickness: Up to 10"
Max Speed X Axis: 120 Feet Per Min.
Max Speed Y Axis: 120 Feet Per Min.
Spindle Motor Power: 13 3/4 HP
Drilling Speeds: 0-545 RPM (Continuously Variable)
Drilling Feed Rate: 2”-10” Per Min. (Infinitely Variable)
Spindle Stroke: 13” Max.
Total Power: 20 HP (14.9 kW)
Power Supply: 208 to 575V, 3-Ph, 60 Hz (50Hz Available)
Average Output: 200 to 400 Holes Per Hour
